N-Tron® 102MC Media Converters

102MC Media Converters

Red Lion's N-Tron® series 102MC media converters offer wide operating temperatures in a small footprint. With excellent EMI protection and a DIN rail-metal mountable housing, discover how our 102 media converters can easily expand your industrial Ethernet network.

Connectivity:
The 102MC media converters provides one RJ45 copper Ethernet port and one fiber optic cabling port. The RJ45 port is available in 10/100BaseTX. The fiber optic port is available with 10BaseFL or 100BaseFX speeds supporting industry standard SC or ST fiber connectors.

Environmental:
The N-Tron series 102MC industrial media converters feature an operating temperature up to -40° to 80°C for use in extreme environments. Housed in a metal enclosure with DIN-rail mounts and ESD protected circuitry, our media converters will remain running trouble-free for years.

Performance:
102MC media converters use built-in switching technology to distinguish port speeds. This means that 10Mbps devices can be connected to 100Mbps networks without issue. Our media converters will auto-sense network environments and provide the best performance possible. The 102MC series support straight-through or cross-over cable communication.

Power Input:
Supporting redundant power inputs, the 102MC media converters accept 10 to 30 VDC input power.

Products:

Part # Total Ports 10/100 Ports 100 Fiber Ports IP Rating Operating Temp Distance Rating Fiber Type Mounting Case
102MC-SC 2 1 1 IP30 -40° to 80°C 2km Multimode DIN-Rail metal
102MC-SC-MDR 2 1 1 IP30 -40° to 80°C 2km Multimode DIN-Rail metal
102MC-ST 2 1 1 IP30 -40° to 80°C 2km Multimode DIN-Rail metal
102MC-ST-MDR 2 1 1 IP30 -40° to 80°C 2km Multimode DIN-Rail metal
102MCE-SC-15 2 1 1 IP30 -40° to 80°C 15km Singlemode DIN-Rail metal
102MCE-SC-15-MDR 2 1 1 IP30 -40° to 80°C 15km Singlemode DIN-Rail metal
102MCE-ST-15 2 1 1 IP30 -40° to 80°C 15km Singlemode DIN-Rail metal
102MCE-ST-15-MDR 2 1 1 IP30 -40° to 80°C 15km Singlemode DIN-Rail metal
102MCE-SC-40 2 1 1 IP30 -40° to 80°C 40km Singlemode DIN-Rail metal
102MCE-SC-40-MDR 2 1 1 IP30 -40° to 80°C 40km Singlemode DIN-Rail metal
102MCE-ST-40 2 1 1 IP30 -40° to 80°C 40km Singlemode DIN-Rail metal
102MCE-ST-40-MDR 2 1 1 IP30 -40° to 80°C 40km Singlemode DIN-Rail metal
102MCE-SC-80 2 1 1 IP30 -40° to 80°C 80km Singlemode DIN-Rail metal
102MCE-SC-80-MDR 2 1 1 IP30 -40° to 80°C 80km Singlemode DIN-Rail metal
102MCE-ST-80 2 1 1 IP30 -40° to 80°C 80km Singlemode DIN-Rail metal
102MCE-ST-80-MDR 2 1 1 IP30 -40° to 80°C 80km Singlemode DIN-Rail metal
